515ACAM457000CAGR,Si515贴片晶振,457kHz,Skyworks晶振,LVPECL差分晶振
编码为515ACAM457000CAGR的Si515贴片晶振是美国Skyworks晶振，该晶振的频率为457KHz，输出方式是LVPECL输出，是差分晶振输出的一种，为LVPECL差分晶振，该晶振的电压是3.3V，频率公差为±20ppm，工作温度是-40°C~85°C，电流为46mA，尺寸是3225mm。差分晶振LV-PECL，Skyworks差分晶振，3225差分晶振。3225mm体积非常小的SMDcrystal器件，是民用小型无线数码产品的最佳选择，小体积的晶振被广泛应用到，手机蓝牙，GPS定位系统，无线通讯集，高精度和高频率的稳定性能，非常好的减少电磁干扰的影响，是民用无线数码产品最好的选择，符合RoHS/无铅。
515ACAM457000CAGR,Si515贴片晶振,457kHz,Skyworks晶振,LVPECL差分晶振
|
原产编码 |
515ACAM457000CAGR |
|
品牌 |
Skyworks晶振 |
|
型号 |
Si515 |
|
频率 |
457kHz |
|
输出方式 |
LVPECL |
|
电压 |
3.3V |
|
工作温度 |
﹣40℃~85℃ |
|
精度 |
±20ppm |
|
电流 |
46mA |
|
尺寸 |
3225mm |
515ACAM457000CAGR,Si515贴片晶振,457kHz,Skyworks晶振,LVPECL差分晶振
更多相关晶振参考
| 原产编码 | 品牌 | 型号 | 频率 | 输出方式 | 电压 |
| 515CAAM100000AAGR | Skyworks晶振 | Si515 | 100kHz | CMOS | 3.3V |
| 515CAB32M7680AAGR | Skyworks晶振 | Si515 | 32.768MHz | CMOS | 3.3V |
| 515CBA4M09600AAGR | Skyworks晶振 | Si515 | 4.096MHz | CMOS | 3.3V |
| 515CDA8M00000AAGR | Skyworks晶振 | Si515 | 8MHz | CMOS | 3.3V |
| 515GCA10M0000AAGR | Skyworks晶振 | Si515 | 10MHz | CMOS | 2.5V |
| 515CAA10M0000BAGR | Skyworks晶振 | Si515 | 10MHz | CMOS | 3.3V |
| 515CAA22M5792BAGR | Skyworks晶振 | Si515 | 22.5792MHz | CMOS | 3.3V |
| 515CAA24M5760BAGR | Skyworks晶振 | Si515 | 24.576MHz | CMOS | 3.3V |
| 515CAA27M0000BAGR | Skyworks晶振 | Si515 | 27MHz | CMOS | 3.3V |
| 515CAA4M09600BAGR | Skyworks晶振 | Si515 | 4.096MHz | CMOS | 3.3V |
| 515CAA7M37472BAGR | Skyworks晶振 | Si515 | 7.37472MHz | CMOS | 3.3V |
| 515CAA80M0000BAGR | Skyworks晶振 | Si515 | 80MHz | CMOS | 3.3V |
| 515CAAM172162BAGR | Skyworks晶振 | Si515 | 172.162kHz | CMOS | 3.3V |
| 515CAB27M0000BAGR | Skyworks晶振 | Si515 | 27MHz | CMOS | 3.3V |
| 515CAB4M09600BAGR | Skyworks晶振 | Si515 | 4.096MHz | CMOS | 3.3V |
| 515CAB5M00000BAGR | Skyworks晶振 | Si515 | 5MHz | CMOS | 3.3V |
| 515CBA24M0000BAGR | Skyworks晶振 | Si515 | 24MHz | CMOS | 3.3V |
| 515CBA36M8640BAGR | Skyworks晶振 | Si515 | 36.864MHz | CMOS | 3.3V |
| 515CBA38M4000BAGR | Skyworks晶振 | Si515 | 38.4MHz | CMOS | 3.3V |
| 515CBA80M0000BAGR | Skyworks晶振 | Si515 | 80MHz | CMOS | 3.3V |
| 515CBB14M3182BAGR | Skyworks晶振 | Si515 | 14.3182MHz | CMOS | 3.3V |
| 515CBB27M0000BAGR | Skyworks晶振 | Si515 | 27MHz | CMOS | 3.3V |
| 515CBB6M00000BAGR | Skyworks晶振 | Si515 | 6MHz | CMOS | 3.3V |
| 515CCA10M0000BAGR | Skyworks晶振 | Si515 | 10MHz | CMOS | 3.3V |
| 515CCA122M880BAGR | Skyworks晶振 | Si515 | 122.88MHz | CMOS | 3.3V |
| 515CCA40M0000BAGR | Skyworks晶振 | Si515 | 40MHz | CMOS | 3.3V |
| 515CCA61M4400BAGR | Skyworks晶振 | Si515 | 61.44MHz | CMOS | 3.3V |
| 515CCA64M0000BAGR | Skyworks晶振 | Si515 | 64MHz | CMOS | 3.3V |
