550AD1000M00DG,Si550石英差分晶振,1 GHz,差分晶振LV-PECL,550AF1000M00DG
尺寸7.0*5.0*1.8,mm，频率 1 GHz ，输出方式 LVPECL ，电压 3.3 v ，精度 ±50ppm ，电流 130 mA ，运行温度-40°C ~ 85°C ，也叫作差分晶振LV-PECL，Si550石英差分晶振主要应用于无线通信，智能手机，平板笔记，计算机，全球GPS定位系统，WLAN。康华尔电子拥有先进的生产设备,早在多年前就获得美国Skyworks晶振代理权限，康华尔进口晶振代理商提供多种晶振封装尺寸，型号齐全，价格优势，交期快，同时免费提供现货样品以及技术支持服务，欢迎广大用户咨询选购。
550AD1000M00DG,Si550石英差分晶振,1 GHz,差分晶振LV-PECL,550AF1000M00DG
|
原产编码 |
550AD1000M00DG |
550AF1000M00DG |
|
品牌 |
Skyworks晶振 |
Skyworks晶振 |
|
型号 |
Si550 |
Si550 |
|
频率 |
1 GHz |
1 GHz |
|
输出方式 |
LVPECL |
LVPECL |
|
电压 |
3.3V |
3.3V |
|
工作温度 |
-40°C ~ 85°C |
-40°C ~ 85°C |
|
精度 |
±50ppm |
±50ppm |
|
电流 |
130mA |
130mA |
|
尺寸 |
7050mm |
7050mm |
550AD1000M00DG,Si550石英差分晶振,1 GHz,差分晶振LV-PECL,550AF1000M00DG
更多相关晶振参考
| 原产编码 | 品牌 | 型号 | 频率 | 输出方式 | 电压 |
| 550CE100M000DG | Skyworks晶振 | Si550 | 100MHz | CMOS | 3.3V |
| 550BJ25M0000DG | Skyworks晶振 | Si550 | 25MHz | LVDS | 3.3V |
| 550CE102M400DG | Skyworks晶振 | Si550 | 102.4MHz | CMOS | 3.3V |
| 550CD16M0000DGR | Skyworks晶振 | Si550 | 16MHz | CMOS | 3.3V |
| 550CD20M0000DGR | Skyworks晶振 | Si550 | 20MHz | CMOS | 3.3V |
| 550CD30M0000DGR | Skyworks晶振 | Si550 | 30MHz | CMOS | 3.3V |
| 550CF10M0000DGR | Skyworks晶振 | Si550 | 10MHz | CMOS | 3.3V |
| 550CD16M0000DG | Skyworks晶振 | Si550 | 16MHz | CMOS | 3.3V |
| 550CD20M0000DG | Skyworks晶振 | Si550 | 20MHz | CMOS | 3.3V |
| 550CD30M0000DG | Skyworks晶振 | Si550 | 30MHz | CMOS | 3.3V |
| 550CF10M0000DG | Skyworks晶振 | Si550 | 10MHz | CMOS | 3.3V |
| 550CJ22M5790DG | Skyworks晶振 | Si550 | 22.579MHz | CMOS | 3.3V |
| 550CM22M5790DG | Skyworks晶振 | Si550 | 22.579MHz | CMOS | 3.3V |
| 550CM94M0000DG | Skyworks晶振 | Si550 | 94MHz | CMOS | 3.3V |
| 550CJ22M5790DGR | Skyworks晶振 | Si550 | 22.579MHz | CMOS | 3.3V |
| 550CM22M5790DGR | Skyworks晶振 | Si550 | 22.579MHz | CMOS | 3.3V |
| 550CM94M0000DGR | Skyworks晶振 | Si550 | 94MHz | CMOS | 3.3V |
| 550AD10M0000DGR | Skyworks晶振 | Si550 | 10MHz | LVPECL | 3.3V |
| 550AD12M5458DGR | Skyworks晶振 | Si550 | 12.5458MHz | LVPECL | 3.3V |
| 550AD24M5760DGR | Skyworks晶振 | Si550 | 24.576MHz | LVPECL | 3.3V |
| 550AD27M0000DGR | Skyworks晶振 | Si550 | 27MHz | LVPECL | 3.3V |
| 550AD94M0000DGR | Skyworks晶振 | Si550 | 94MHz | LVPECL | 3.3V |
| 550BD62M5000DGR | Skyworks晶振 | Si550 | 62.5MHz | LVDS | 3.3V |
| 550FD74M2500DGR | Skyworks晶振 | Si550 | 74.25MHz | LVDS | 2.5V |
| 550RC12M2230DGR | Skyworks晶振 | Si550 | 12.223MHz | LVPECL | 2.5V |
| 550AJ873M515DG | Skyworks晶振 | Si550 | 873.515MHz | LVPECL | 3.3V |
| 550AJ873M515DGR | Skyworks晶振 | Si550 | 873.515MHz | LVPECL | 3.3V |
