瑞萨XFC晶振中物料编码为XFC236156.250000I的晶振频率是156.25MHz，其输出方式为CML输出，为CML输出晶振，该晶振的电压是3.3V，频率公差为±25ppm，其运行温度是-40°C~85°C，尺寸为2520mm。该晶振也叫瑞萨CML输出晶振，Renesas CML输出晶振，2520贴片晶振。2520mm体积的晶振,可以说是目前小型数码产品的福音,目前超小型的智能手机里面所应用的就是小型的石英晶振,该产品最适用于无线通讯系统,无线局域网,已实现低相位噪声,低电压,低消费电流和高稳定度,超小型,质量轻等产品特点,产品本身编带包装方式,可对应自动高速贴片机应用,以及高温回流焊接,为无铅产品。
XFC236156.250000I,瑞萨XFC晶振,156.25MHz,CML输出晶振
|
原产编码 |
XFC236156.250000I |
|
品牌 |
Renesas |
|
型号 |
XFC |
|
频率 |
156.25MHz |
|
输出方式 |
CML |
|
电压 |
3.3V |
|
工作温度 |
﹣40℃~85℃ |
|
精度 |
±25ppm |
|
电流 |
- |
|
尺寸 |
2520mm |
XFC236156.250000I,瑞萨XFC晶振,156.25MHz,CML输出晶振
更多相关晶振参考
| 编码 | 品牌 | 型号 | 频率 | 输出方式 | 电压 | 精度 |
| XLL528200.000000X | Renesas | XPRESSO FXO-LC52 | 200MHz | LVDS | 2.5V | ±20ppm |
| XFP236156.250000I | Renesas | XFP | 156.25MHz | LVPECL | 3.3V | ±25ppm |
| XPC736156.250000I | Renesas | XPC | 156.25MHz | CML | 3.3V | ±25ppm |
| XPP736156.250000I | Renesas | XPP | 156.25MHz | LVPECL | 3.3V | ±25ppm |
| XPP736312.500000I | Renesas | XPP | 312.5MHz | LVPECL | 3.3V | ±25ppm |
| XLH735050.000000X | Renesas | XPRESSO FXO-HC73 | 50MHz | HCMOS | 3.3V | ±50ppm |
| XLH735001.000000X | Renesas | XPRESSO FXO-HC73 | 1MHz | HCMOS | 3.3V | ±50ppm |
| XLH536040.000000I | Renesas | XPRESSO FXO-HC53 | 40MHz | HCMOS | 3.3V | ±25ppm |
| XLH536012.000000I | Renesas | XPRESSO FXO-HC53 | 12MHz | HCMOS | 3.3V | ±25ppm |
| XLH536027.000000I | Renesas | XPRESSO FXO-HC53 | 27MHz | HCMOS | 3.3V | ±25ppm |
| XLH536048.000000I | Renesas | XPRESSO FXO-HC53 | 48MHz | HCMOS | 3.3V | ±25ppm |
| XLH736010.000000I | Renesas | XPRESSO FXO-HC73 | 10MHz | HCMOS | 3.3V | ±25ppm |
| XLH736024.000000I | Renesas | XPRESSO FXO-HC73 | 24MHz | HCMOS | 3.3V | ±25ppm |
| XLH736033.333000I | Renesas | XPRESSO FXO-HC73 | 33.333MHz | HCMOS | 3.3V | ±25ppm |
| XLH736050.000000I | Renesas | XPRESSO FXO-HC73 | 50MHz | HCMOS | 3.3V | ±25ppm |
| XLH736001.000000I | Renesas | XPRESSO FXO-HC73 | 1MHz | HCMOS | 3.3V | ±25ppm |
| XLH736040.000000I | Renesas | XL | 40MHz | HCMOS | 3.3V | ±25ppm |
| XLH536008.000000I | Renesas | XPRESSO FXO-HC53 | 8MHz | HCMOS | 3.3V | ±25ppm |
| XLH736125.000000I | Renesas | XPRESSO FXO-HC73 | 125MHz | HCMOS | 3.3V | ±25ppm |
| XLH536028.636360I | Renesas | XPRESSO FXO-HC53 | 28.63636MHz | HCMOS | 3.3V | ±25ppm |
| XLH330012.000000I | Renesas | XL | 12MHz | HCMOS | 3.3V | ±100ppm |
| XLH736200.000000I | Renesas | XPRESSO FXO-HC73 | 200MHz | HCMOS | 3.3V | ±25ppm |
| XLH536125.000000I | Renesas | XPRESSO FXO-HC53 | 125MHz | HCMOS | 3.3V | ±25ppm |
| XLH536012.288000I | Renesas | XPRESSO FXO-HC53 | 12.288MHz | HCMOS | 3.3V | ±25ppm |
