544BAAC000159CCG,148.5 MHz,LVDS晶振Si544,Skyworks贴片晶振

544BAAC000159CCG,148.5 MHz,LVDS晶振Si544,Skyworks贴片晶振544BAAC000159CCG,148.5 MHz,LVDS晶振Si544,Skyworks贴片晶振

产品简介

544BAAC000159CCG,148.5 MHz,LVDS晶振Si544,Skyworks贴片晶振

编码为544BAAC000159CCG的LVDS晶振Si544频率为148.5 MHz，电压1.8V、 2.5V、3.3V，电流111mA，精度±20ppm，工作温度-40°C ~ 85°C，尺寸是3225mm，为3225晶振、3.2*2.5贴片晶振，输出方式是LVDS，为LVDS差分贴片晶振，3225 贴片晶振是市场上最常用的封装尺寸晶振，是被公认最适合在汽车电子上的产品

产品详情

ggt1

544BAAC000159CCG,148.5 MHz,LVDS晶振Si544,Skyworks贴片晶振

编码为544BAAC000159CCG的LVDS晶振Si544频率为148.5 MHz，电压1.8V、 2.5V、3.3V，尺寸是3225mm，为3225晶振、3.2*2.5贴片晶振，输出方式是LVDS，为LVDS差分贴片晶振，3225 贴片晶振是市场上最常用的封装尺寸晶振，是被公认最适合在汽车电子上的产品。3225 Skyworks贴片晶振均符合欧盟环保 ROHS 标准,满足无铅高温回流焊接曲线要求,康华尔电子正规授权代理商 0755-27838351

ggt2

544BAAC000159CCG,148.5 MHz,LVDS晶振Si544,Skyworks贴片晶振

原产编码

544BAAC000159CCG

品牌

Skyworks晶振

型号

Si544

频率

148.5 MHz

输出方式

LVDS

电压

1.8V, 2.5V, 3.3V

工作温度

﹣40℃~85℃

精度

±20ppm

电流

111mA

尺寸

3225mm

si544 ggs

ggt3

544BAAC000159CCG,148.5 MHz,LVDS晶振Si544,Skyworks贴片晶振

si544 cct3225

更多 相关晶振参考

原产编码 品牌 型号 频率 输出方式 电压
544DABB001892BCG Skyworks晶振 Si544 100MHz CML 1.8V~3.3V
544DABB001893BCG Skyworks晶振 Si544 100MHz CML 1.8V~3.3V
544BACC000112ACG Skyworks晶振 Si544 10MHz LVDS 1.8V~3.3V
544AAAA000118ACG Skyworks晶振 Si544 156.25MHz LVPECL 2.5V~3.3V
544AADA000163ACG Skyworks晶振 Si544 20MHz LVPECL 2.5V~3.3V
544BADB001939ACG Skyworks晶振 Si544 150.060024MHz LVDS 1.8V~3.3V
544BACB001962ACG Skyworks晶振 Si544 121.3056MHz LVDS 1.8V~3.3V
544CACC000306ACG Skyworks晶振 Si544 22.5792MHz CMOS 1.8V~3.3V
544AAAA000798ACG Skyworks晶振 Si544 1MHz LVPECL 2.5V~3.3V
544BAAC001713ACG Skyworks晶振 Si544 325MHz LVDS 1.8V~3.3V
544CACC000627ACG Skyworks晶振 Si544 10MHz CMOS 1.8V~3.3V
544BACB001952ACG Skyworks晶振 Si544 202.5MHz LVDS 1.8V~3.3V
544BACB001808ACG Skyworks晶振 Si544 270MHz LVDS 1.8V~3.3V
544BACB001939ACG Skyworks晶振 Si544 150.060024MHz LVDS 1.8V~3.3V
544BAAC000627ACG Skyworks晶振 Si544 10MHz LVDS 1.8V~3.3V
544BACC001530ACG Skyworks晶振 Si544 148.5MHz LVDS 1.8V~3.3V
544BACB001961ACG Skyworks晶振 Si544 121.306MHz LVDS 1.8V~3.3V
544AAAA000126ACG Skyworks晶振 Si544 200MHz LVPECL 2.5V~3.3V
544BACB001960ACG Skyworks晶振 Si544 227.272727MHz LVDS 1.8V~3.3V
544CAAC000306ACG Skyworks晶振 Si544 22.5792MHz CMOS 1.8V~3.3V
544BAAC001741ACG Skyworks晶振 Si544 70.656MHz LVDS 1.8V~3.3V
544BADB000991ACG Skyworks晶振 Si544 135MHz LVDS 1.8V~3.3V
544ACAA001427BCGR Skyworks晶振 Si544 157MHz LVPECL 2.5V~3.3V
544DABB001897BCG Skyworks晶振 Si544 100MHz CML 1.8V~3.3V
544CAAA000956BCG Skyworks晶振 Si544 6.78MHz CMOS 1.8V~3.3V
544AAAA000121BCG Skyworks晶振 Si544 100MHz LVPECL 2.5V~3.3V
544DABB001896BCG Skyworks晶振 Si544 100MHz CML 1.8V~3.3V
544DABB001895BCGR Skyworks晶振 Si544 100MHz CML 1.8V~3.3V
544BACC000118BCGR Skyworks晶振 Si544 156.25MHz LVDS 1.8V~3.3V
544BACB001960ACGR Skyworks晶振 Si544 227.272727MHz LVDS 1.8V~3.3V
544BAAB001011BCGR Skyworks晶振 Si544 148.5MHz LVDS 1.8V~3.3V
544DABB001890BCG Skyworks晶振 Si544 100MHz CML 1.8V~3.3V
544CBCB000112BCGR Skyworks晶振 Si544 10MHz CMOS 1.8V~3.3V
544GAAA000112BCGR Skyworks晶振 Si544 10MHz CMOS 1.8V~3.3V
544BCAC002065BCGR Skyworks晶振 Si544 272.8MHz LVDS 1.8V~3.3V
544BBAC001541BCGR Skyworks晶振 Si544 96MHz LVDS 1.8V~3.3V
544BCAA000126BCGR Skyworks晶振 Si544 200MHz LVDS 1.8V~3.3V
544DABB001894BCG Skyworks晶振 Si544 100MHz CML 1.8V~3.3V
544BCAA000136BCGR Skyworks晶振 Si544 160MHz LVDS 1.8V~3.3V
544BAAC000111BCG Skyworks晶振 Si544 25MHz LVDS 1.8V~3.3V
544AADA000163ACGR Skyworks晶振 Si544 20MHz LVPECL 2.5V~3.3V
544BAAA000137BCG Skyworks晶振 Si544 1.024GHz LVDS 1.8V~3.3V
544ACAC000112BCGR Skyworks晶振 Si544 10MHz LVPECL 2.5V~3.3V
544BACA000420BCG Skyworks晶振 Si544 644.53125MHz LVDS 1.8V~3.3V
544AAAA000112BCGR Skyworks晶振 Si544 10MHz LVPECL 2.5V~3.3V
544BAAA000137BCGR Skyworks晶振 Si544 1.024GHz LVDS 1.8V~3.3V
544AAAA000126ACGR Skyworks晶振 Si544 200MHz LVPECL 2.5V~3.3V
544CCAC000121BCG Skyworks晶振 Si544 100MHz CMOS 1.8V~3.3V
544ACAC000112BCG Skyworks晶振 Si544 10MHz LVPECL 2.5V~3.3V
544DABB001897BCGR Skyworks晶振 Si544 100MHz CML 1.8V~3.3V
