Abracon晶振,AB38T-32.768KHZ,32.768K晶振,AB38T时钟晶振,圆柱晶振3×8

Abracon晶振,AB38T-32.768KHZ,32.768K晶振,AB38T时钟晶振,圆柱晶振3×8

Abracon晶振中物料编码为AB38T-32.768KHZ的AB38T时钟晶振，该晶振的频率是32.768kHz，精度为±20ppm，负载电容是12.5pF，其工作温度在-10°C~60°C，尺寸是3.20mmx8.30mm。该晶振也叫美国进口晶振、时钟晶体振荡器，32.768K晶振，圆柱晶振3×8，符合RoHS/RoHS II标准。Abracon总部位于德克萨斯州奥斯汀以外，是一家值得信赖的领先和创新电子元件供应商，包括频率控制、定时、电源、磁性、RF和天线解决方案。Abracon为数据通信、运输、工业、医疗、消费、航空航天和国防行业的世界级公司提供服务，通过提供无与伦比的产品解决方案、技术专业知识和卓越的服务，加快了客户的上市时间。

ggt2 Abracon晶振,AB38T-32.768KHZ,32.768K晶振,AB38T时钟晶振,圆柱晶振3×8

编码	AB38T-32.768KHZ
品牌	Abracon晶振
型号	AB38T
频率	32.768kHz
频率公差	±20ppm
负载电容	12.5pF
工作温度	-10°C~60°C
尺寸	3.20mmx8.30mm

ggt3 Abracon晶振,AB38T-32.768KHZ,32.768K晶振,AB38T时钟晶振,圆柱晶振3×8

AB38T cct

更多相关晶振参考

物料编码	品牌	型号	频率	频率公差	负载电容	工作温度
ABS06-32.768KHZ-6-T	Abracon晶振	ABS06	32.768kHz	±20ppm	6pF	-40°C~85°C
AB38T-32.768KHZ	Abracon晶振	AB38T	32.768kHz	±20ppm	12.5pF	-10°C~60°C
ABM8-27.120MHZ-10-D1G-T	Abracon晶振	ABM8	27.12MHz	±10ppm	10pF	-40°C~85°C
ABM8-24.000MHZ-D1G-T	Abracon晶振	ABM8	24MHz	±10ppm	18pF	-40°C~85°C
AB26T-32.768KHZ	Abracon晶振	AB26T	32.768kHz	±20ppm	12.5pF	-10°C~60°C
ABL-20.000MHZ-B2	Abracon晶振	ABL	20MHz	±20ppm	18pF	-20°C~70°C
ABL-11.0592MHZ-B2	Abracon晶振	ABL	11.0592MHz	±20ppm	18pF	-20°C~70°C
ABL-16.000MHZ-B2	Abracon晶振	ABL	16MHz	±20ppm	18pF	-20°C~70°C
ABL-3.579545MHZ-B2	Abracon晶振	ABL	3.579545MHz	±20ppm	18pF	-20°C~70°C
ABL-8.000MHZ-B2	Abracon晶振	ABL	8MHz	±20ppm	18pF	-20°C~70°C
ABL-7.3728MHZ-B2	Abracon晶振	ABL	7.3728MHz	±20ppm	18pF	-20°C~70°C
ABL-12.000MHZ-B2	Abracon晶振	ABL	12MHz	±20ppm	18pF	-20°C~70°C
ABL-10.000MHZ-B2	Abracon晶振	ABL	10MHz	±20ppm	18pF	-20°C~70°C
ABL-16.384MHZ-B2	Abracon晶振	ABL	16.384MHz	±20ppm	18pF	-20°C~70°C
ABL-4.9152MHZ-B2	Abracon晶振	ABL	4.9152MHz	±20ppm	18pF	-20°C~70°C
ABL-6.000MHZ-B2	Abracon晶振	ABL	6MHz	±20ppm	18pF	-20°C~70°C
ABL-12.288MHZ-B2	Abracon晶振	ABL	12.288MHz	±20ppm	18pF	-20°C~70°C
ABL-18.432MHZ-B2	Abracon晶振	ABL	18.432MHz	±20ppm	18pF	-20°C~70°C
ABL-14.7456MHZ-B2	Abracon晶振	ABL	14.7456MHz	±20ppm	18pF	-20°C~70°C
ABL-3.6864MHZ-B2	Abracon晶振	ABL	3.6864MHz	±20ppm	18pF	-20°C~70°C
ABL-22.1184MHZ-B2	Abracon晶振	ABL	22.1184MHz	±20ppm	18pF	-20°C~70°C
AB308-6.000MHZ	Abracon晶振	AB308	6MHz	±30ppm	16pF	-10°C~60°C
AB308-8.000MHZ	Abracon晶振	AB308	8MHz	±30ppm	16pF	-10°C~60°C
AB308-16.000MHZ	Abracon晶振	AB308	16MHz	±30ppm	16pF	-10°C~60°C
ABS05-32.768KHZ-7-T	Abracon晶振	ABS05	32.768kHz	±20ppm	7pF	-40°C~85°C
AB-10.000MHZ-B2	Abracon晶振	AB	10MHz	±20ppm	18pF	-20°C~70°C
ABS05-32.768KHZ-X-T5	Abracon晶振	ABS05	32.768kHz	±20ppm	4pF	-40°C~85°C
AB-1.8432MHZ-B2	Abracon晶振	AB	1.8432MHz	±20ppm	18pF	-20°C~70°C
ABM11-25.000MHZ-16-D-T	Abracon晶振	ABM11	25MHz	±30ppm	16pF	-40°C~85°C
