美国瑞萨晶振中物料编码为XLH73V016.986000X的XL VCXO晶振，该晶振的频率是16.986MHz，输出方式为HCMOS输出，是为HCMOS输出差分晶振，其电压是3.3V，该晶振的工作温度是-20°C~70°C，电流是32mA，尺寸是7050mm，该晶振也叫瑞萨7050晶振，7050 SMD晶振，瑞萨六脚SMD晶振，HCMOS输出差分晶振，Renesas差分晶振，差分晶体振荡器，VCXO晶振。压控晶体振荡器由于具有频率可调的特点，成为各种接收机和应答机中不可或缺的关键部件。在这些设备中，为了补偿晶振长期老化、收发信号间多普勒频移等因素的影响，通常要求压控晶振具有较宽的压控范围; 并且，为了适应野外、 空间等工作环境，还要求在宽温范围内具有良好的频率温度稳定性。
XL VCXO晶振,XLH73V016.986000X,瑞萨7050晶振,16.986MHz
|
原产编码 |
XLH73V016.986000X |
|
品牌 |
Renesas |
|
型号 |
XL |
|
频率 |
16.986MHz |
|
输出方式 |
HCMOS |
|
电压 |
3.3V |
|
精度 |
- |
|
工作温度 |
-20°C~70°C |
|
电流 |
32mA |
|
尺寸 |
7050mm |
XL VCXO晶振,XLH73V016.986000X,瑞萨7050晶振,16.986MHz
更多相关晶振参考
|
编码 |
品牌 |
型号 |
类型 |
频率 |
|
XLH53V012.288000I |
XPRESSO FVXO-HC53 |
VCXO |
12.288MHz |
|
|
XLH73V024.576000I |
Renesas |
XPRESSO FVXO-HC73 |
VCXO |
24.576MHz |
|
XLH53V010.000000I |
Renesas |
XPRESSO FVXO-HC53 |
VCXO |
10MHz |
|
XLH73V027.000000I |
Renesas |
XPRESSO FVXO-HC73 |
VCXO |
27MHz |
|
XLP73V153.600000I |
Renesas |
XPRESSO FVXO-PC73 |
VCXO |
153.6MHz |
|
XLH73V073.728000I |
Renesas |
XPRESSO FVXO-HC73 |
VCXO |
73.728MHz |
|
XLH73V074.250000I |
Renesas |
XPRESSO FVXO-HC73 |
VCXO |
74.25MHz |
|
XLL73V148.351648I |
Renesas |
XPRESSO FVXO-LC73 |
VCXO |
148.351648MHz |
|
XLP73V500.000000I |
Renesas |
XPRESSO FVXO-PC73 |
VCXO |
500MHz |
|
XLH53V025.000000X |
Renesas |
XPRESSO FVXO-HC53 |
VCXO |
25MHz |
|
XLP73V775.069300I |
Renesas |
XPRESSO FVXO-PC73 |
VCXO |
775.0693MHz |
|
XLL73V148.500000I |
Renesas |
XPRESSO FVXO-LC73 |
VCXO |
148.5MHz |
|
XLH53V026.000000I |
Renesas |
XL |
VCXO |
26MHz |
|
XLH73V140.160000I |
Renesas |
XL |
VCXO |
140.16MHz |
|
XLH73V178.125000I |
Renesas |
XL |
VCXO |
178.125MHz |
|
XLH73V138.240000I |
Renesas |
XL |
VCXO |
138.24MHz |
|
XLH73V192.000000I |
Renesas |
XL |
VCXO |
192MHz |
|
XLH73V199.680000I |
Renesas |
XL |
VCXO |
199.68MHz |
|
XLH73V142.500000I |
Renesas |
XL |
VCXO |
142.5MHz |
|
XLH53V137.500000I |
Renesas |
XL |
VCXO |
137.5MHz |
|
XLH73V145.500000I |
Renesas |
XL |
VCXO |
145.5MHz |
|
XLH73V144.500000I |
Renesas |
XL |
VCXO |
144.5MHz |
|
XLH73V184.320000I |
Renesas |
XL |
VCXO |
184.32MHz |
|
XLH73V187.500000I |
Renesas |
XL |
VCXO |
187.5MHz |
|
XLH73V153.600000I |
Renesas |
XL |
VCXO |
153.6MHz |
|
XLH53V200.000000I |
Renesas |
XL |
VCXO |
200MHz |
|
XLH53V122.880000K |
Renesas |
XL |
VCXO |
122.88MHz |
|
XLH73V060.000000X |
Renesas |
XPRESSO FVXO-HC73 |
VCXO |
60MHz |
|
XLH53V009.843000I |
Renesas |
XPRESSO FVXO-HC53 |
VCXO |
9.843MHz |
|
XLH72V150.000000X |
Renesas |
XPRESSO FVXO-HC72 |
VCXO |
150MHz |
|
XLH72V070.000000I |
Renesas |
XPRESSO FVXO-HC72 |
VCXO |
70MHz |
|
XLH73V250.000000X |
Renesas |
XPRESSO FVXO-HC73 |
VCXO |
250MHz |
|
XLH73V234.375000X |
Renesas |
XPRESSO FVXO-HC73 |
VCXO |
234.375MHz |
|
XLH73V176.000000X |
Renesas |
XPRESSO FVXO-HC73 |
VCXO |
176MHz |
