5G室外基站控制器TG-5006CJ爱普生压控温补晶振X1G004131003700输出VC-TCXO

4G模块与5G模块或基于FR-4的、具有用于I/O的建构的组件.如上所述,当选定晶振时,有许多不同的选择要考虑.然而,通过检查使用晶振的系统,爱普生晶振最方便的选择将变得显而易见；例如可用于为晶振供电的输入电压以及振荡器的输出将驱动的器件的类型等因素.还必须考虑应用的其它约束条件,例如物理尺寸和操作环境.除了这些基本参数之外,针对特定应用,还有许多其它规范要予以考量.但当将这些因素通盘考虑后,很可能会找到一款满足系统要求的晶振.

TG-5006CJ爱普生压控温补晶振X1G004131003700,5G室外基站控制器输出VC-TCXO晶振

爱普生有源晶振编码	型号	频率	长X宽X高	输出波	电源电压	削顶正弦波; 削峰正弦波;
X1G004131000400	TG-5006CJ	26.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	1.700 to 1.900 V	Clipped sine wave
X1G004131000600	TG-5006CJ	16.367667 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131000700	TG-5006CJ	16.368000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131000800	TG-5006CJ	16.369000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131000900	TG-5006CJ	19.200000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131001000	TG-5006CJ	26.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131001100	TG-5006CJ	38.400000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131001300	TG-5006CJ	16.367667 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131001400	TG-5006CJ	16.368000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131001500	TG-5006CJ	16.369000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131001600	TG-5006CJ	19.200000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131001700	TG-5006CJ	26.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131001800	TG-5006CJ	38.400000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	1.700 to 3.300 V	Clipped sine wave
X1G004131002600	TG-5006CJ	40.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131002900	TG-5006CJ	19.200000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.600 to 3.000 V	Clipped sine wave
X1G004131003100	TG-5006CJ	40.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131003200	TG-5006CJ	26.635300 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.700 to 3.465 V	Clipped sine wave
X1G004131003300	TG-5006CJ	28.974000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.700 to 3.465 V	Clipped sine wave
X1G004131003400	TG-5006CJ	26.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	1.700 to 1.900 V	Clipped sine wave
X1G004131003600	TG-5006CJ	26.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.660 to 2.940 V	Clipped sine wave
X1G004131003700	TG-5006CJ	19.200000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.660 to 2.940 V	Clipped sine wave
X1G004131003800	TG-5006CJ	26.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	1.700 to 1.900 V	Clipped sine wave
X1G004131004100	TG-5006CJ	40.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131004200	TG-5006CJ	32.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	2.850 to 3.150 V	Clipped sine wave
X1G004131004400	TG-5006CJ	24.576000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	3.135 to 3.465 V	Clipped sine wave
X1G004131004900	TG-5006CJ	26.000000 MHz	2.00 x 1.60 x 0.73 mm	VC-TCXO~TCXO	1.700 to 1.900 V	Clipped sine wave
X1G004201000600	TG-5006CE	16.367667 MHz	3.20 x 2.50 x 0.90 mm	VC-TCXO~TCXO	1.700 to 1.900 V	Clipped sine wave

通用振荡器框图.Generic XO Block Diagram:通用简单晶振框图Oscillator circuit: 振荡器电路Output: 输出Generic VC-TCXO Block diagram: 日本进口晶振通用压控温度补偿晶振框图Temperature dependent compensation voltage generator: 依赖电压发生器的温度补偿Varactor diode: 变容二极管Generic OCXO Block diagram: 通用恒温控制晶振框Oven cavity: 烤腔Temp sensor: 温度传感器Oscillator: 振荡器RF OUTPUT: RF输出 Output amp: 输出放大器Setpoint: 设置点Proportional controller: 比例控制器 eater: 加热器
