ECS汽车行业应用产品

在现代智能汽车的设计和制造中，电子元件的质量和可靠性至关重要。ECS晶振公司拥有业界最广泛的AEC-Q200频率控制产品选择。我们还提供宽温度范围的标准产品和设计用于恶劣环境的加固产品。

ECS公司开发了新产品来帮助提高汽车应用的性能。我们的产品提供业界最小的封装尺寸。每个部分都经过性能优化，以提高整体性能，例如确保将要使用的设备快速启动。它们外形小巧，易于实施。低等效串联电阻(ESR)和低负载电容(LC)便于启动和降低功耗。

实时计时，即满足小时、分钟和秒钟的计时，比以往任何时候都更加成为汽车电子领域的一个重要方面。汽车应用中扩展温度范围内的精度是一个重要考虑因素

ECS晶体振荡器设计应用笔记

什么是振荡器？

振荡器是一种产生重复信号的电子电路。根据应用，该信号可以是多种形式。一些应用程序需要一个基本时钟来维持进程的操作间隔。其他应用要求时钟具有非常清晰的波形和严格的稳定性，以产生高质量的通信和数据传输。

在模拟应用中，例如使用超外差收发信号链的RF无线电收发器，通常会发现正弦输出波形。正弦波是一种连续波，代表平滑的周期性振荡。在RF通信中，石英晶体振荡器正弦波输出为收发器提供精确的低噪声频率参考。

在数字电子学中，我们看到方波输出。方波是一种以稳定频率从最小振幅到最大振幅交替变化的波形。理想方波的最小和最大周期相等，占空比为50/50%。实际上，占空比会有一些变化，因此45/55%或60/40%可能更典型。方波输出信号有许多用途，但广泛用于电路或微处理器中指令执行的定时。

领先同行WI2WI低相位噪声温补晶振专用于M2M通信，TORONTO, Wi2Wi Corporation ("Wi2Wi" or the "Company"), a leading global developer and manufacturer of end to end Wireless Connectivity Solutions, high precision Frequency Control, Timing and Microwave Filter devices, is pleased to announce a rugged, robust and reliable family of Temperature Compensated Crystal Oscillators (TCXO), the TCH series, a further promising extension of its product portfolio.

TSX-V: YTY; Common Shares: 145,663,418

“We are very pleased to announce our new TCH series of rugged and best in class Temperature Compensated Crystal Oscillators (TCXO). The TC6 series further expands Wi2Wi's frequency control and timing devices portfolio to meet the most demanding technical requirements from the Avionics, Space and Military markets. The Company has received the first production orders for the TCH series from a marquee supplier to the Avionics and defense market.” said Michael Sonnenreich, Chairman of the Board.

“Wi2Wi continues to focus extensively on developing new products based upon client demand and assures a full line of products in each category we produce. The new TCH series of TCXO expands our current high stability, high shock and high vibration is ideal for high precision applications in avionics, space and military markets. The TCH series is a nice addition to our family of high reliability and high performing TCXO." said Zachariah Mathews, President and CEO of Wi2Wi.

Specifics on the new product series:

The TCH Series of Temperature Compensated Crystal Oscillator (TCXO) ensures a precise frequency and very high stability under demanding applications in extreme conditions. The TCH series provides excellent phase noise, low jitter, and superior performance in high vibration and high temperature environments. This TCXO is available in rugged package of 5 pin through hole in both standard and custom frequencies from 1.000MHz to 50.000 MHz. The TCH is available in various supply voltages, stability and temperature ranges, stability as low as 0.5ppm with operating temperature from 55°C to +125°C. The TCH series is available various supply voltages; or 5.0v, 12.0v and 15.0v that provides low power supply current incorporating a low power CMOS output.

About IoT and M2M

Essentially, IoT and M2M describethe network of physical objects or "things" embedded with electronics, software, sensors, and network connectivity, which enables these objects to collect and exchange data. Driven by several factors including the growth in the availability of Broadband Internet, which reduces the cost of connecting, and the related increase in Wi-Fi capabilities as well as sensors built into myriad technologies, this has been described as the “perfect storm” for the IoT. Almost any device with an on and off switch that can be connected to the Internet (and/or to each other) – anything from cell phones, coffee makers, washing machines, headphones, lamps, wearable devices, cars, as well as machine components in the engine of a jet airplane or the drill of an oil rig. According to analyst firm Gartner, by 2020 there will be over 26 billion connected devices. Others think this figure could be too conservative by a factor of four.

About Wi2Wi Corporation

Wi2Wi is a vertically-integrated technology company which designs, manufactures and markets high performance, low power wireless connectivity solutions, global navigation satellite system (GNSS) modules, and frequency control devices. The Company's products and services address numerous applications in the markets of Internet of Things (IoT), Machine to Machine (M2M), Avionics, Space, and Government Sponsored Projects. Wi2Wi's products and value-added services provide highly integrated, rugged, robust, and reliable multiprotocol wireless actuators with embedded software, along with customized timing and frequency control devices for customers, worldwide. The Company was founded in 2005 and is strategically headquartered in San Jose, California with satellite offices in Middleton, Wisconsin and Hyderabad, India. Wi2Wi's manufacturing operations, its laboratory for reliability and quality control, together with design and engineering for timing and frequency control devices are located in Middleton, WI. The branch office, located in Hyderabad, India, focuses on the development of wireless connectivity; both hardware and software. Wi2Wi's strategic objective is to service the unique needs of each customer by providing end to end wireless integration solutions and highly customizable timing and frequency control devices. Wi2Wi distinguishes itself from commodity grade products, with best in the market performance, highly reliable, low power wireless connectivity products with integrated software that supports broader temperature ranges and a longer product life cycle. Furthermore, Wi2Wi's end to end product solutions helps the customer substantially reduce their end product expense, certification cost, and overall R&D investment, in addition to substantially reducing the time to market. Wi2Wi has partnered with best in class global leaders in technology, manufacturing, and sales. The Company uses a wide network of manufacturer's representatives, worldwide, to promote its products and services, and has partnered with world class distributors for the fulfillment of orders along with direct sales.

多伦多，Wi2Wi公司全球领先的端到端无线连接解决方案、高精度频率控制、定时和微波滤波设备开发商和制造商(“Wi2Wi”或“公司”)很高兴宣布推出一款坚固、稳定、可靠的温度补偿石英晶体振荡器(TCXO)系列产品TCH系列，这是其产品组合的又一大扩展。

TSX五世:YTY；普通股:145，663，418

“我们非常高兴地宣布我们的新型TCH系列坚固耐用、同类最佳的温度补偿晶体振荡器(TCXO)。TC6系列进一步扩展了Wi2Wi的频率控制和定时设备组合，以满足航空电子、航天和军事市场最苛刻的技术要求。该公司已经从航空电子和国防市场的一家大型供应商那里获得了TCH系列的首批生产订单。”董事会主席迈克尔·索南里奇说。领先同行WI2WI低相位噪声温补晶振专用于M2M通信.

“Wi2Wi继续致力于根据客户需求开发新产品，并确保我们生产的每个类别的产品种类齐全。TCXO的新TCH系列扩展了我们目前的高稳定性、高冲击和高振动，是航空电子、航天和军事市场中高精度应用的理想选择。TCH系列是我们高可靠性和高性能TCXO振荡器家族的又一成员。”Wi2Wi总裁兼首席执行官扎卡里亚·马修斯(Zachariah Mathews)说。

CTS时钟振荡器支持以太网应用，CTS Corporation (NYSE: CTS), founded in 1896, is a global leader in the design and manufacturing of a diverse array of electronic components, sensors and actuators.
CTS Corporation (NYSE: CTS)成立于1896年，是设计和制造各种电子石英晶振元件、传感器和执行器的全球领导者.

Primarily fulfilling the needs of original equipment manufacturers (OEMs), CTS is proud of its over 100-year heritage of innovative products and engineering excellence. CTS products are manufactured utilizing state-of-the-art technology driven by a highly capable and dedicated staff.

In a current vertically integrated era, where applications such as complex data and video along with voice, are increasing in demand, advanced technologies of high-speed information transfer require continuous improvements of information sharing systems. The World Wide Web has become an essential tool in our daily life when it comes to accessing various types of information/business databases, video conferencing or manufacturing networks. Enabling efficient communication flow over existing infrastructure has become challenging in order to satisfy demanding user requirements. High-speed data/video and voice channels along with effective routing systems have been created as a result.

在当前的垂直集成时代，随着需求的增加，高速信息传输的先进技术要求改进信息共享系统。网络已成为我们日常生活中访问各种类型的信息/商业数据库、视频会议或制造网络。通过现有基础设施实现高效的通信流为了满足苛刻的用户要求，变得具有挑战性。高速数据/视频和语音因此，已经创建了具有有效路由系统的信道。
Data Networks

数据网络

For the purpose of this discussion, we can associate the flow of information within network channels to water flow within very complex system of pipelines of different shapes and sizes. Long haul channels that transfer information from state-to-state or city-to-city are called “TRUNKS”. Trunks connect multiple central office locations while utilizing fiber optics and high bandwidth cabling meshes along with highspeed routers and core switching systems. This accommodates the transfer of heavy masses of data packets (also called high band width data transporters). Once data packets reach a given central office destination (close-by to the final destination of the end user), they are transferred through soft-switching equipment to narrower data transport channels ultimately leading to the end-users (subscribers).

为了进行讨论，我们可以将网络渠道内的信息流与水在不同形状和尺寸的非常复杂的管道系统中流动。长途通道从一个州到另一个州或从一个城市到另一座城市的信息传递被称为“TRUNKS”。中继线连接多个中心办公室位置，同时利用光纤和高带宽布线网络以及高速路由器和核心交换系统。这可以容纳大量数据的传输数据包（也称为高带宽数据传送器）。一旦数据包到达给定的中心局目的地（靠近最终用户的最终目的地），它们通过软交换进行传输设备到更窄的数据传输信道，最终导致最终用户（订户）。

In many cases the subscribers are located within enterprises (i.e. business organizations, hospitals, office buildings, etc.) that share internal communication lines and network channels to support several business activities. In such cases, an internal high-speed network is typically installed.

在许多情况下，订阅者位于企业内部（即商业组织、医院、办公室建筑物等）共享内部通信线路和网络通道以支持多个业务活动。在这种情况下，通常会安装内部高速网络。

Ethernet Standard

以太网标准

Ethernet has evolved into the most widely implemented networking protocol today. Fast Ethernet increased the data speed from 10 Megabits per second (Mbits/s) to 100 Mbit/s to and from the users terminal. Gigabit Ethernet was the next iteration, increasing the speed to 1,000 Mbit/s. The initial standard for Gigabit Ethernet was issued by the IEEE in June 1998 as IEEE 802.3z.

以太网已发展成为当今实现最广泛的网络协议。而以太网需要进口晶体振荡器支持，快速以太网将往返用户的数据速度从每秒10兆比特提高到每秒100兆比特航空站千兆以太网是下一代，将速度提高到1000 Mbit/s。初始标准IEEE于1998年6月发布了用于千兆以太网的IEEE 802.3z。

Gigabit Ethernet access equipment is available in different speeds and bandwidth. Most common systems operate with 3.125Gbits/sec and 10Gbits/sec. 10 Gigabit Ethernet over twisted pair has just been completed, but as of June 2006, the only currently available adapters for copper wire requires special cabling and is limited to 15 meters for point-to-point communications. Major Gigabit Ethernet manufacturers include Cisco Systems, Broadcom (chipset manufacturer), Netgear, D-Link, Intel, Adtran and others.
千兆以太网接入设备有不同的速度和带宽。最常见系统以3.125Gbits/sec和10Gbits/sec运行。双绞线上的万兆以太网已完成，但截至2006年6月，目前唯一可用的铜线适配器需要特殊布线，点对点通信限制在15米以内。主要千兆以太网制造商包括Cisco Systems、Broadcom（芯片组制造商）、Netgear、D-Link、Intel、Adtran以及其他。CTS时钟振荡器支持以太网应用.
